Manual double seat irrigation valve plastic
Manual double seat irrigation valve plastic
Manual double seat irrigation valve plastic
Manual double seat irrigation valve plastic
Manual double seat irrigation valve plastic
Manual double seat irrigation valve plastic
Manual double seat irrigation valve plastic

Manual double seat irrigation valve plastic

Model NO.:
KLBVM20---110
Price:
USD 1.20-39.00 / set
Delivery:
FOB
Minimum order quantity:
1 set
Supply Ability:
200000 set / Year
Country of Origin:
TIANJIN
  • Place of Origin:CN;HEB
  • Application:General
  • Temperature of Media:Normal Temperature
  • Power:Manual
  • Media:Water
  • Structure:BALL
  • Brand Name:YDKL
  • Model Number:KLBVM20---110
  • Port Size:1/2"-4"
  • Material:PVC
  • Pressure:200psi/PN16
  • Temperature:0-27 Degree-C
  • Standard:DIN/ JIS / ANSI /BS/CNS
  • Connect way:Socket / Thread / Flange
  • Design:Full Port Design
  • O-Ring:Double O-Ring Stem Seal
  • Seals:FPM or EPDM Seals
  • Torque:low torque and adjustable seat retainer
  • Product name:manual double seat irrigation valve plastic
Product Description
Product name:manual double seat irrigation valve plastic

Design Advantages:

1.  Heavy-duty, extra-large diameter shaft is reinforced by additional resin and eliminates stem breaks.
2.  Double shaft O-rings.
3.  PTFE seats backed up with O-rings reduce the wear and tear of repeated cycling.


4. Self compensation of thermal expansion and micro-adjustment of the PTFE ball seats

5.  Concentric machined and mirror-polished ball.
6.  Dual sliding seats use triple O-rings for balance and maximum leak protection.

7. Smooth flow path eliminates pressure loss.

Design Advantages:

8.  True union ends for ease of piping and removal.
9.  Easy actuation, even after installation.
10. Handle can be replaced by actuator directly, no need to mount brackets

FEARTURES

Size: DN15-1/2"to DN100-4"
Material: PVC / PP / CPVC /PVDF
Liner: EPDM / FPM
Connect Way: Thread / Slip /Flange
Standard: DIN / ANSI /JIS / NPT/ BSPT
Options: Manual Type /ready for actuator type/Pneumatic and Electric actuator type

And you may leave us message for more information.

NO
PARTS
PCS
MATERIALS
1
Cap
1
PVC
2
Handle
1
PVC
3
O-ring
2
EPDM
4
Stem
1
PVC
5
Seal Carrier
1
PVC
6
Ball
1
PVC
7
Ball Seat
2
PTFE
8
O-ring
2
EPDM
9
O-ring
1
EPDM
10
End Connector
2
PVC
11
Union Nut
2
PVC
12
Body
1
PVC
13
Flange
1
PVC
14
O-ring
2
EPDM
