Model NO.
KLTM20----110
Price:
USD 1.90-50.00 / set
Delivery:
FOB
Minimum order quantity:
1 set
Supply Ability:
200000 set / Year
Country of Origin:
TIANJIN
Quantity:
  • Type:BALL VALVES
  • Place of Origin:CN;HEB
  • Application:General
  • Temperature of Media:Normal Temperature
  • Media:Water
  • Structure:BALL
  • Brand Name:YDKL
  • Model Number:KLTM20----110
  • Port Size:1/2",---,2'',3'',4''
  • Power:Manual/electric/pneumatic
  • Material:PVC
  • Pressure:200psi/PN16
  • Temperature:0-27 Degree-C
  • Standard:DIN/ JIS / ANSI /BS/CNS
  • Connect way:Socket / Thread / Flange
  • Design:Full Port Design
  • O-Ring:Double O-Ring Stem Seal
  • Seals:FPM or EPDM Seals
  • Torque:low torque and adjustable seat retainer
  • Product name:2 way gray high pressure plastic TU true union ball valve

2 way gray high pressure plastic TU true union ball valve

Product Description



2 way gray high pressure TU true union ball valve



Ask a question about this product...



FEATURES

Size: DN15-1/2” to DN100-4”

Material: PVC / PP / CPVC /PVDF

Liner: EPDM / FPM

Connect Way: Thread / Slip /Flange

Standard: DIN / ANSI /JIS / NPT/ BSPT

Options: Manual Type /ready for actuator type/Pneumatic and Electric actuator type

2 way gray high pressure TU true union ball valve

2 way gray high pressure TU true union ball valve

EXPLOSIVE CHART

2 way gray high pressure TU true union ball valve





NO

PARTS

PCS

MATERIALS

1

Cap

1

PVC

2

Handle

1

PVC

3

O-ring

2

EPDM

4

Stem

1

PVC

5

Seal Carrier

1

PVC

6

Ball

1

PVC

7

Ball Seat

2

PTFE

8

O-ring

2

EPDM

9

O-ring

1

EPDM

10

End Connector

2

PVC

11

Union Nut

2

PVC

12

Body

1

PVC

13

Flange

1

PVC

14

O-ring

2

EPDM



Product Details

2 way gray high pressure TU true union ball valve

  • Packaging

ball valve



Products Catalog

2 way gray high pressure TU true union ball valve

-Comply with ASTM standard, ROSH environmental certification, SGS certification.

-Promise to use new materials.

-Advanced production equipment to ensure the quality of the valves.

-100% pre-sale leak-proof test.

Click here for more information...

Company Information

 2 way gray high pressure TU true union ball valve

Why choose us?

-Professional technical team,quickly feedback customized solutions.

-Comply with ASTM standard, ROSH environmental certification, SGS certification.

-Promise to use new materials.

-Advanced production equipment to ensure the quality of the valves.

-100% pre-sale leak-proof test.

FAQ

FAQ

Q:Are you trading company or manufacturer ?
A:We are professional manufacturer,specialized in VALVES for many years.

Q:How about OEM or ODM?
A:YDKL have experienced technical team,which can design the valve according to customized request.

Q:How long is your delivery time?
A:Generally,It is 7 days for the conventional product in stock,otherwise it is 20-30 days after deposit.Urgent order can be negotiable.

Q:Do you provide samples ?
A:Absolutely! But we consider to receive small amount of sample fee as a sign of sincerely cooperation and will compensate it in products for your future order.

Q:Can I have my own Logo on the product?
A:Yes, sure,if your quantity is considerable,we would like to engraved your logo in the products.
